Hunter Pro-C Modular 4 Station Indoor Controller | HTRPC400I

• 4 to 32 stations
• Modular
• For indoor use
• 1 sensor input port
• Not Wi-Fi enabled

Hunter's residential controllers offer simple to advanced automatic watering with an abundance of user-friendly features. Most Hunter controllers can be upgraded to "smart controllers" by adding sensors. Since 2001, the Pro-C has been the contractor's choice in residential irrigation control. The Pro-C has proven to be the most reliable and robust controller in the industry, with the flexibility to expand on demand due to its modular design.

Pro-C users can now add more stations than ever before, in the same compact package they've come to know and trust. Compatibility with simple and affordable two-wire control makes the Pro-C the perfect solution for light commercial projects such as business parks, city parks, schools, and multi-family housing complexes.

The Pro-C and all AC-powered Hunter controllers are now EPA WaterSense labeled when paired with the Solar Sync weather sensor.

• 3 independent irrigation programs (4 start times each) allow for customized scheduling
• Dimensions:
  • Height: 9"
  • Width: 10"
  • Depth: 4 1/2"
• Transformer input: 120 VAC
• Transformer output: (24 VAC): 1 A
• Station output (24 VAC): 0.56 A
• P/MV output (24 VAC): 0.28 A

• 1 sensor input available for use with Solar Sync® or any Clik sensors

• 1 P/MV output for pump start relay and master valve activation

• Dedicated Solar Sync dial position provides logic for smart water savings

• Easy Retrieve memory allows for manual backup and retrieval of preferred settings and programming

• QuickCheck provides simple diagnostics of faulty field wiring

• 3 independent lighting programs available for simultaneous irrigation and lighting control

• Power cord not included
• 2-year warranty

Watersense Smart Watering Controller By Adding Solar Sync

By adding a Solar Sync to your Hunter controller, it transforms into a smart controller using local weather conditions to tailor watering schedules to actual conditions on the site. A Hunter controller with Solar Sync has been independently proven to have a detailed list of water-saving features and has been approved by the EPA as a WaterSense Smart Watering Controller. Click here to learn more about Smart Controllers.

Easy Retrieve Memory

A manual backup utility that stores complete controller scheduling and setup information in backup memory. This allows the saved watering schedule to be restored at any time. This can be used to set a controller back to its initial settings after tampering or at the beginning of a new season.

Automatic Short Circuit Protection

Automatic short circuit protection is a feature found in all Hunter AC-powered controllers. This feature automatically detects electrical faults, which are typically caused by wiring issues. Only affected stations are skipped, allowing all other stations to water normally as programmed. There are no fuses to blow or internal circuit breakers to trip, so complete irrigation system shutdown is avoided.

Quick Check

The QuickCheck feature makes field wiring issues easy to assess with the push of a button. QuickCheck displays an ERR message when a field wiring short is detected on a particular station number.

Seasonal Adjustment: Global Or Automatic Updates With Solar Sync

This feature allows for quick adjustments to irrigation run times through a percentage scale. During peak season, set the seasonal adjustment to 100%. If weather conditions require less water, enter the appropriate percentage value (i.e. 50%) to cut down irrigation run times without the need to adjust each station in the program. This model offers two different ways to use Seasonal Adjustment to reduce water usage: Global and Daily.

Global: The Global option provides a Seasonal Adjustment percentage to all station Run Times on all of the controller's Programs.

Daily: With the addition of a Solar Sync ET Sensor, the controller has the ability to automatically implement daily adjustments based on measured local weather.

Delay Between Stations

Users can program a delay between stations as the controller advances from one station to the next. This delay can range from a few seconds (to permit slow-closing valves additional time to close) to a much longer period of time (to allow pressure tanks time to recharge), based on user requirements.

Sensor Programmability

The ability to specify which program will be shut down in response to a specific sensor alarm. This allows programs unaffected by the sensor to continue automatic operations.

Non-Water Days

Day(s) of the week can be programmed OFF in advance so that irrigation does not occur regardless of program interval schedules. For example, if the gardener mows the lawn on Saturday, the Non-Water Days feature allows Saturday to be programmed to OFF so that watering will not occur.
