Hunter PRO Adjustable Nozzle 10 ft

Part #
HTR10A
MFG #
10A

Hunter PRO Adjustable Nozzle 10 ft

Part #
HTR10A
MFG #
10A
Login or Register to view pricing and availability
Free Shipping on Orders over $149

Product Image Feedback

Shop for Hunter Spray Nozzle, 10' 0 - 360° Adjustable 0.2 - 2.36 gpm Red

  • Radius: 10'
  • Flow Rate: 0.2 - 2.36 GPM
  • Adjustable from 0° to 360°
  • Trajectory: 15°

Features and Benefits

Whether dealing with hillside topography, a curved flowerbed, or other special landscape installations, challenging angles demand nozzles that adjust to their surroundings. Hunter Pro Adjustable Nozzles cover any angle needed on any landscape with the accuracy of a fixed nozzle. Engineered to emit larger than average water droplets, these nozzles are reliable, accurate, and fully adjustable to any angle from 0° to 360°. Pro Adjustable Nozzles are available in seven models that cover distances from 4' to 17' using recommended pressure. For easy inventory and field ID, models are color-coded based on throw distance.

Product Details

  • Adjustable from 0° to 360° for maximum design flexibility

  • Easy-grip top for simple adjustment

  • Strong edges for a defined pattern with better wind resistance

  • Large water droplets minimize misting with better uniformity

  • Recommended operating pressure: 30 PSI
ARC PSI RADIUS FT. FLOW GPM  PRECIP IN/HR  PRECIP IN/HR
20 9 0.20 1.90 2.20
25 10 0.23 1.92 2.22
30 10 0.25 1.93 2.22
35 11 0.28 1.92 2.22
40 11 0.30 1.88 2.17
ARC PSI RADIUS FT. FLOW GPM  PRECIP IN/HR  PRECIP IN/HR
20 9 0.40 1.90 2.20
25 10 0.45 1.92 2.22
30 10 0.50 1.93 2.22
35 11 0.55 1.92 2.22
40 11 0.59 1.88 2.17
ARC PSI RADIUS FT. FLOW GPM  PRECIP IN/HR  PRECIP IN/HR
20 9 0.53 1.90 2.20
25 10 0.60 1.92 2.22
30 10 0.67 1.93 2.22
35 11 0.73 1.92 2.22
40 11 0.79 1.88 2.17
ARC PSI RADIUS FT. FLOW GPM  PRECIP IN/HR  PRECIP IN/HR
20 9 0.80 1.90 2.20
25 10 0.90 1.92 2.22
30 10 1.00 1.93 2.22
35 11 1.10 1.92 2.22
40 11 1.18 1.88 2.17
ARC PSI RADIUS FT. FLOW GPM  PRECIP IN/HR  PRECIP IN/HR
20 9 1.07 1.90 2.20
25 10 1.20 1.92 2.22
30 10 1.33 1.93 2.22
35 11 1.47 1.92 2.22
40 11 1.57 1.88 2.17
ARC PSI RADIUS FT. FLOW GPM  PRECIP IN/HR  PRECIP IN/HR
20 9 1.20 1.90 2.20
25 10 1.35 1.92 2.22
30 10 1.50 1.93 2.22
35 11 1.65 1.92 2.22
40 11 1.77 1.88 2.17
ARC PSI RADIUS FT. FLOW GPM  PRECIP IN/HR  PRECIP IN/HR
20 9 1.60 1.90 2.20
25 10 1.80 1.92 2.22
30 10 2.00 1.93 2.22
35 11 2.20 1.92 2.22
40 11 2.36 1.88 2.17
Brand:
Hunter
Part Number:
HTR10A
