• Up to 6 sprinkler zones
• Quick and easy to install
• LNK WiFi compatible

• Controls up to 6 sprinkler zones.
• Quick to Install. Suitable for indoor or outdoor installations. Factory-installed 6’ outdoor-rated power cord for your convenience
• Simple to Program. Quickly program a schedule in just 3 steps. NEW large back-lit LCD display for improved visibility in low-light and direct sunlight conditions WiFi Connectivity
• Advanced Features. Contractor Default™ allows you to easily save and restore your custom schedule. Delay Watering up to 14 days and automatically resume watering after the set delay has elapsed.
• Compatible with the new Rain Bird LNK WiFi module (sold separately). Simply plug in the module to access, operate and monitor your irrigation system from any mobile device.

Zones/Stations 6
Indoor/Outdoor Indoor/Outdoor
Controller Type Fixed Station
Dimensions

• Width: 7.92 in. (20,1 cm)
• Height: 7.86 in. (20,0 cm)
• Depth: 3.51 in. (9,0 cm)

Features Delay Between Stations, Manual Watering, Master Valve/Pump Start, Non-volatile Memory, Rain Delay, Seasonal Adjust, Water Budget
Programs 3
Program Day Cycles Custom days of the Week, Odd days, Even days, Cyclical (water every x days), Calendar day off, Event days off
Start Times per Zone/Program 4
Electrical Specifications

• Input required: 120VAC (±10%) @ 60Hz
• Output: 1A at 24VAC
• Master Valve/Pump Start Relay

External battery backup is not required. Nonvolatile memory permanently saves the current programming and a 10-year life lithium battery maintains the controller's time and date during power outages.
Certifications UL, cUL, FCC Part 15b, IP24
